What hardware does the Nedis WIFIP121FWT use?
The socket contains a CB2S module with a BK7231N Wi-Fi SoC and a BL0937 metering chip on the main PCB [Elektroda, elurkki, post #20237392]
Nedis Wi-Fi Smart Plug WIFIP121FWT (BK7231N, BL0937, CB2S)
TL;DR
- Nedis Wi‑Fi Smart Plug WIFIP121FWT was opened, identified as a BK7231N-based CB2S smart plug, and flashed with OpenBeken firmware.
- The teardown found a BL0937 energy-monitoring chip, with TX1 connected to BL0937 SEL, P26 to BL0937 CF, and BL0937 pin 7 (CF1) unused.
- Flashing used a FTDI USB-to-TTL adapter on 3.3V, GND, TX, RX and CEN, then uartprogram wrote OpenBK7231N_QIO_1.14.1.bin to 0x0.
- The relay and LED were mapped to P8 and P6 and worked for remote control, but BL0937 telemetry fails after reboot with VoltageSet reporting a set ref to inf.
Generated by the language model.
About The Device
Nedis Wi-Fi Smart Plug WIFIP121FWT, Remote controllable plug with energy monitoring.
Disassembled
The plug itself
To remove the bottom cover, there is need only for simple small screw driver. The cover has small fastener in the each corner of the cover. A bit force is needed, but not that much there is any fear of breaking the cover.
There seems to be CB2S BK7231N inside the plug
And the energy monitorig chip is BL0937
Flasing
Since I am not electronics guy, I couldn't find regulator from the PCB. There might be, but I went through all chips which I found and none of them were regulator for my eyes. So I used normal FTDI USB to TTL adapter. I soldered short cables to the 3.3V, GND, TX, RX and CEN pins of the BK7231N module.
Connected everything like this:
Fetched the binary from:
https://github.com/openshwprojects/OpenBK7231T_App
Flasher from:
https://github.com/OpenBekenIOT/hid_download_py
Once done I started flasher in my linux machine and connected the CEN pin to GND for 1seconds.
uartprogram ~/Downloads/OpenBK7231N_QIO_1.14.1.bin -d /dev/ttyUSB0 --unprotect -w --startaddr 0x0
And the result was this:
UartDownloader....
programm....
Gotten Bus... : | |[ ?k/s]caution: ignoring unexpected reply in SetBaudRate
Write Successful: |##################################################|[ 16.8k/s]
Pinout
Before assembling everything back I used multimeter to check where the pins are connected from module to energy monitoring chip. Other pins were a bit tough for me so I decided to test those in the configuration.
BL0937 pin 7 (CF1) was not connected to anywhere.
Job done
Once the work was done. I removed the wires from the module and plugged in the just flashed plug. Connected to the plug with phone and changed proper SSID and PSK for it.
Then rebooted it and connected to it from my desktop and everything seems to be working so far.
Configuration
Tested where the relay is connected (not TX1 which I assume would be pin 11, and pin 26 since those are energy monitor chip). Found out that relay starts to give nice sound when configured to P8. LED started to work at P6.
Then configured 11 to be BL0937SEL and 26 to BL0937CF
The problem
The relay works so the plug can be remotely controlled. Unfortunately the BL0937 is not automatically starting up during reboot. When using command startDriver BL0937 the chip seems to be available, but once trying to give VoltageSet etc.. there is just information:
Info:EnergyMeter:VoltageSet: you gave 230.000000, set ref to inf
The index page seems like this after the VoltageSet (or after any BL0937 command)
Any tips are welcome to continue from this.
Thanks a lot!
Nedis Wi-Fi Smart Plug WIFIP121FWT, Remote controllable plug with energy monitoring.
Disassembled
The plug itself
To remove the bottom cover, there is need only for simple small screw driver. The cover has small fastener in the each corner of the cover. A bit force is needed, but not that much there is any fear of breaking the cover.
There seems to be CB2S BK7231N inside the plug
And the energy monitorig chip is BL0937
Flasing
Since I am not electronics guy, I couldn't find regulator from the PCB. There might be, but I went through all chips which I found and none of them were regulator for my eyes. So I used normal FTDI USB to TTL adapter. I soldered short cables to the 3.3V, GND, TX, RX and CEN pins of the BK7231N module.
Connected everything like this:
| Module | USB to TTL |
| 3.3V | 3.3V |
| GND | GND |
| TX | RX |
| RX | TX |
Fetched the binary from:
https://github.com/openshwprojects/OpenBK7231T_App
Flasher from:
https://github.com/OpenBekenIOT/hid_download_py
Once done I started flasher in my linux machine and connected the CEN pin to GND for 1seconds.
uartprogram ~/Downloads/OpenBK7231N_QIO_1.14.1.bin -d /dev/ttyUSB0 --unprotect -w --startaddr 0x0
And the result was this:
UartDownloader....
programm....
Gotten Bus... : | |[ ?k/s]caution: ignoring unexpected reply in SetBaudRate
Write Successful: |##################################################|[ 16.8k/s]
Pinout
Before assembling everything back I used multimeter to check where the pins are connected from module to energy monitoring chip. Other pins were a bit tough for me so I decided to test those in the configuration.
| Module | Connected to |
| TX1 | BL0937 SEL (pin 8) |
| P26 | BL0937 CF |
BL0937 pin 7 (CF1) was not connected to anywhere.
Job done
Once the work was done. I removed the wires from the module and plugged in the just flashed plug. Connected to the plug with phone and changed proper SSID and PSK for it.
Then rebooted it and connected to it from my desktop and everything seems to be working so far.
Configuration
Tested where the relay is connected (not TX1 which I assume would be pin 11, and pin 26 since those are energy monitor chip). Found out that relay starts to give nice sound when configured to P8. LED started to work at P6.
Then configured 11 to be BL0937SEL and 26 to BL0937CF
The problem
The relay works so the plug can be remotely controlled. Unfortunately the BL0937 is not automatically starting up during reboot. When using command startDriver BL0937 the chip seems to be available, but once trying to give VoltageSet etc.. there is just information:
Info:EnergyMeter:VoltageSet: you gave 230.000000, set ref to inf
The index page seems like this after the VoltageSet (or after any BL0937 command)
Any tips are welcome to continue from this.
Thanks a lot!
Comments
Hey @elurkki , thanks for the post and the teardown, I will add it to our online teardowns database. Regarding your issue.... that's strange, please give me a while to investigate. I will update my... [Read more]
Hi, You are absolutely correct! I opened the plug again and measured all the pins again. The pin 6 was just covered something and didn't give values until I used a bit force to get some values. Sorry... [Read more]
I'm happy that it worked out. You might also consider updating to latest version, because it is capable of reporting average power consumption during last hour. [Read more]
Hi. Tested how the OTA updating works, and it was really fluent. I do now have 1.14.10 version uploaded to the plug. The Consumption is shown nicely on the plugin web page. Is it possible to get the... [Read more]
I am not sure if I understand. Are you asking if the "Energy Consumed Last Hour" is included in the Home Assistant Discovery? If so, then no, you'd have to take it out manually. Only Voltage, Current... [Read more]
version 1.14.11 should report alls topic in Home Assistant Discovery. It should post: 1x relay 6x sensors (voltage, current, power, energycounter, energycounter_last_hour, consumption_stats) 5x sensor... [Read more]
As a reader, I do not know what the author of the above-mentioned of the article he meant. :D [Read more]
This article by a friend from the USA or abroad, was machine translated, shows the inside of a smart WiFi socket and documents what's inside (what WiFi module and what energy measurement system) so... [Read more]
Sorry my mistake it was already introduced in earlier version 1.14.7. But confirmed it on my MQTT log, where discovery message was sent from device, may be HA ignored it.???? I am not really familiar... [Read more]
@valeklubomir it might be good to ask @iprak as he is doing the Discovery features. Also, was the energycounter_last_hour included in the HA discovery? https://github.com/openshwprojects/OpenBK7231T_App/blob/main/src/httpserver/hass.c ... [Read more]
I have executed Start Home Assistant Discovery and MQTT received following messages: Topic: homeassistant/switch/OpenBK7231N_8D1B2BE5_relay_0/config QOS: 2 Data: {"dev":{"ids":["OpenBK7231N_8D1B2BE5"],"name":"obk8D1B2BE5","sw":"1.0.3","mf":"Beken... [Read more]
@valeklubomir I am testing your new stats system for power consumption (measure the power consumption during last hour and a total one) and I must admit it's great addition! Thank you. https://obrazki.elektroda.pl/8969808000_1666100294_thumb.jpg... [Read more]
