Inside the Triki motion controller and a bit of reverse engineering
TL;DR
- The Triki motion controller uses a Nordic nRF52810 BLE SoC and a mysterious SF 248 MEMS sensor.
- The PCB also carries exposed programming pads and a 1MB Macronix MX25R8035F flash chip that appears mostly filled with FFs.
- Reverse engineering used an Android phone, Bluetooth logging, USB debugging, ADB bugreport output, and Wireshark analysis of the Bluetooth logs.
- The BLE communication runs over Nordic UART Service (NUS), which revealed commands for starting sensor data transmission and turning on the built-in LED.
- The nRF52810 is locked, the pinout remains unconfirmed without a J-LINK programmer, and the SF 248 sensor still lacks a clear datasheet or online reference.
Generated by the language model.
Hi everyone, today I’d like to show you the inside of the controller Tricks , which has become the flagship product of the green amphibian retail chain. It allows you to play games via the chain’s dedicated app.
As we can see in the photo above, at the heart of the device is the SoC chip nRF52810 from Nordic Semiconductor, an energy-efficient Bluetooth Low Energy (BLE) microcontroller based on the ARM Cortex-M4. It is very popular in small IoT devices and wireless accessories. The chip is locked, and to unlock it, you need to erase its contents.
Typical applications of the nRF52810:
Quote:Bluetooth locators (beacons, tags)
Motion and activity sensors
Smart buttons and BLE remotes
Fitness trackers and wearables
Smartphone accessories
BLE keyboards and mice
Smart locks
Temperature, humidity and environmental sensors
Gaming gadgets using BLE
The MEMS sensor is the SF 248 (probably LSM6DSL) ,
On the PCB, there are exposed programming pads,
Interestingly, the board also features a FLASH memory chip, according to a dump from the user’s GitHub Piwencjusz R80B..... R80X..... ( 1MB Macronix MX25R8035F ) with some very interesting content; apart from the header shown below, the rest is filled with nothing but ‘FFs’, which might give us plenty of scope for DIY projects.
Time to reverse-engineer the BLE protocol and find out ‘how it all works’.
To eavesdrop on the communication, all I needed was an Android phone, an app dedicated to the controller, Bluetooth logging and USB debugging enabled in the developer options, and ADB on the computer, so that after listening in, a report could be generated from the system using the command:
adb bugreport c:\log.zipOnce the report is complete, an archive should appear log.zip on the C: drive. The Bluetooth log is located at: \FS\data\misc\bluetooth\logs .
It’s plain sailing from here – just import it into Wireshark and analyse it.
Summary:
I’ve managed to find out that communication takes place via Nordic UART Service (NUS) – which command to use to start data transmission from the sensors, or even to light up the built-in LED.
Below are some example videos of what we’ve managed to achieve so far:
PS Everything I’m presenting here was done for educational purposes. I really like this gadget and think it’s worth popularising.
PPS I’ve added a few interesting facts from the user Piwencjusz GitHub
Useful links:
mipix wrote:
GitHub kawaczek
GitHub koksny
GitHub Wojtekb30
GitHub Ciol8
GitHub Maku-hub
GitHub egortar-pi
GitHub Diego7120
GitHub ekl3m
GitHub kumpelstachu
