[BK7231T] Teardown Action LCS Smart Plug (without Energy Meter) 2578685
As I already did a teardown, a second one is no problem.
This is the LCS Smart Power Plug Article number: 2578685.
I got acquainted with ELEKTRODA as I bought this plug, hoping it contained an ESP82xx. Well, I got disappointed (again); this unit doesn't have an ESP82xx. As this was the 6th unit I ordered not contain an ESP82xx, I figured. Is there a replacement? And yes, there was. @p.kaczmarek2 has been a great help, and I am pretty happy with the updates and changes he committed to the code.
Well, let us start again;
Unpacking:
The unit comes in a little square box
Physical appearance:
Opening up:
Even though not needed as cloud-cutter works OK, I did open up the LSC plug.
Opening the plug is very easy. It is locked/snapped in the corners; if you put a knife or small screwdriver near the edge and gentry pry, it will pop open.
Closing is also effortless, snap the chassis back in, and you will hear a click once.
The inside:
And the stuff we care about:
These plugs do have a drawback; they are mislabeled. The Tuya board is labeled CB2S, which should be a BK7231N, but once you remove the label on the chip, it is a BK7231T. This did result in some extra frustration in the beginning, but once this was clarified, flashing went quickly.
And because we are using cloud-cutter, there is no need for soldering.
Flashing is straightforward, and I've attached the whole process.
I choose the 1.1.8 BK7231T / oem_bk7231s_rnd_switch and SS01S Single Pole Smart Light Switch (TreatLife)
PINs
As this is a very basic plug, there is not much configuring.
PIN6 LED_n 1
PIN7 Btn 1
PIN8 Rel_1 1
PIN26 Wifi
And finished
iled 0
Cheers
Added after 2 [hours] 46 [minutes]:
My little collection;
I will head to the office to configure all these for our ceiling lamps.
NIels
This is the LCS Smart Power Plug Article number: 2578685.
I got acquainted with ELEKTRODA as I bought this plug, hoping it contained an ESP82xx. Well, I got disappointed (again); this unit doesn't have an ESP82xx. As this was the 6th unit I ordered not contain an ESP82xx, I figured. Is there a replacement? And yes, there was. @p.kaczmarek2 has been a great help, and I am pretty happy with the updates and changes he committed to the code.
Well, let us start again;
Unpacking:
The unit comes in a little square box
Physical appearance:
Opening up:
Even though not needed as cloud-cutter works OK, I did open up the LSC plug.
Opening the plug is very easy. It is locked/snapped in the corners; if you put a knife or small screwdriver near the edge and gentry pry, it will pop open.
Closing is also effortless, snap the chassis back in, and you will hear a click once.
The inside:
And the stuff we care about:
These plugs do have a drawback; they are mislabeled. The Tuya board is labeled CB2S, which should be a BK7231N, but once you remove the label on the chip, it is a BK7231T. This did result in some extra frustration in the beginning, but once this was clarified, flashing went quickly.
And because we are using cloud-cutter, there is no need for soldering.
Flashing is straightforward, and I've attached the whole process.
I choose the 1.1.8 BK7231T / oem_bk7231s_rnd_switch and SS01S Single Pole Smart Light Switch (TreatLife)
PINs
As this is a very basic plug, there is not much configuring.
PIN6 LED_n 1
PIN7 Btn 1
PIN8 Rel_1 1
PIN26 Wifi
And finished
iled 0
Cheers
Added after 2 [hours] 46 [minutes]:
My little collection;
I will head to the office to configure all these for our ceiling lamps.
NIels
